技术细节
内容
| Item | NAME | Parameter |
|---|---|---|
| 1 | Carbon Fiber frame | Size: 328mmW328mmH57mm, Wheelbase: 417mm |
| 2 | Weight | 1.0kg (NO Battery) ; 1.5kg (6S-5000mAh Battery) |
| 3 | Main motor | #3110 KV; 800 Motors |
| 4 | Blade | 4*1050 X3 propellers |
| 5 | Flight control module | F722 F435 Flight Controller |
| 6 | Electric control module | Four in one-6S 32-bit 70A. |
| 7 | FPV Camera | 1200TVL, Sensor: 1/2.7-inch, DC 5V; |
| 8 | Thermal imaging | Heat source detection up to 300 meters away; |
| 9 | Image TX | 5.8G Remote image transmission module; |
| 10 | Receiver | ELRS receiver, Supports 915M frequency band; |
| 11 | Flight parameters | RC distance: 5-10KM; Flight Speed: 140KM/h; |
| 12 | Flight Time | ≈30Min (Empty hover) / ≈15Min (Load Weight 3.0kg); |
| 13 | Operating Temperature | -30°C ~ +70°C |
| 14 | High rate lithium batteries | Li-po 6S 22.2V 8000mAh T60 Joint; |
| 15 | Lithium battery charger | UP9 charger, 150W, Max output 15A; |
| 16 | Remote control | 915MHz frequency band, Hall high-sensitivity control handle; |
| 17 | UAV VR Glasses | 5.8G frequency band 800 line resolution; |
